激光切割服务

激光切割灵活高效，可高质量快速切割复杂图形。

State-of-the-art automated laser cutters need little manpower. Combining their autonomous nature with their swiftness, Ferrnx’s online laser cutting service enables keeping your project costs low.

定位精度公差为±0.1毫米，热影响极小，可切割最小直径为材料厚度一半的小孔，且无需追加加工即可攻丝，大多数材料切缝宽度小于0.5毫米。

Fractory’s manufacturing network offers lasers that can cut a number of materials. These include carbon steel, stainless steel, high-strength steels as well as non-ferrous materials like aluminium, brass, copper and titanium. For metal plates thicker than 20 mm, see more about our plasma cutting capabilities. Aluminium cutting has its own rules.

Fractory’s laser profiling service only focuses on one group of materials – different types of metal. Therefore, we include a list of most common metals with their maximum recommended thickness for getting the best quality results:

Mild steel – up to 30 mm

Stainless steel – up to 30 mm

Special steels (Hardox, Strenx, etc.) – up to 20 mm

Coated steel – up to 5 mm

Aluminium – up to 30 mm

Copper alloys – up to 12 mm

激光也可切割多种非金属材料（如MDF、亚克力、木材、纸板等），但目前我们暂不提供此类服务。

在线激光切割可为小批量（5000英镑以下）及打样订单提供即时报价。无最小订单量限制，只需上传3D模型或DXF图纸，即可获取报价与交期，确认后由我们完成生产和交付。

Online laser cutting’s pricing algorithms make it possible to design parts keeping cost in mind already in the prototyping phase, facilitating scaling up the production later on. On the platform, you’re able to see how the prices change when playing around with different quantities and materials.

流程如下：

• Go to Ferrnx’s platform.
• 上传CAD文件，建议用3D模型（支持STP、SLDPRT、IPT），可同时报价折弯件。平面切割亦可使用DXF二维图纸。
• 选择材料及收货地址，即时获取价格和交期。
• 我们负责全英配送，覆盖伦敦、利物浦等主要城市。

如有疑问，请查看激光切割报价页面或邮件咨询工程师。

Prototypes created from sheet metal are functional prototypes, not mock-up models that don’t possess the same material characteristics as the final product. Thus, in many industries, sheet metal and CNC prototypes are preferred to 3D-printed ones.

每种工艺各有优劣，建议根据实际需求选择。我们的工程师可为您评估最优、最经济的方案。

激光切割是一种利用高能激光束进行热切割的工艺，适用于各种金属加工，包括工业生产，可获得高质量效果。

激光切割较等离子切割更精确、能耗低，但厚板切割能力有限。

Fractory’s CNC laser cutting service offers CO2 and fibre lasers. While both use concentrated laser beams, the beam generation process uses different mechanisms. Both technologies have certain advantages, making them useful in certain situations.

如前所述，激光切割在多个方面优于其他切割方式，了解其优势将有助于您的项目。

激光切割主要优势：

• Great flexibility – One sheet may have 100 different cuts without having to change tools. Also, it is possible to cut all kinds of intricate shapes.
• Precision – Accuracy of+/- 0.1 mm for laser cut parts gives the possibility to really cater to your most demanding needs. This kind of precision also ensures high quality.
• Repeatability – +/- 0.05 mm ensures close to identical details.
• Speed – Laser cutters are known for their speed, especially when cutting thin metal sheets.
• Saves money – The machines are getting more energy efficient. Shuttle tables reduce the need for handling which means less need for manual labour. Smaller manufacturing costs result in lower total costs for the buyer.
• Saving time – CNC laser cutting is automated. Therefore, it is the machinery that reads the drawings. The drawings only need to include cutting lines. This saves a lot of time in the drawing-room.
• Small areas of HAZ – The heat affected zone is an unwanted byproduct of thermal cutting methods. As laser cutting has a small cutting kerf, the heat is not dispersed as heavily as with other cutting methods, leaving a smaller HAZ.
